Low Watt Density PTFE Immersion Heater Chemical Resistant For Semiconductor
Excellent Chemical Resistance Low Watt Density Immersion PTFE Semiconductor Heater
Voltage: 110V-480V
Power: 3KW-36KW/Set
Dimension: According to the tanks size of customer
Material: PTFE+PFA heating wire
Usage: Put on the bottom of the chemical tank to heat up the tank solutions.
Industries
Semiconductor
Ultra-High-Purity Solutions
Surplus designs and manufactures thermal solutions and power supplies to meet the most stringent cleanroom, ultra-high-purity (UHP) processes, and customer requirements of the Semiconductor and Wafer Processing industries.
Applications
- Wet-Deposition
- Flammable Solvent Heating
- Chemical Heating
- RO/DI Water Heating
- Ultra-High-Purity Heating
PRODUCT OVERVIEW
Heaters For Semiconductor are great for heating fluid baths to a constant temperature. These heaters are ideal for use in the semiconductor, pharmaceutical, and biomedical industries. These immersion heaters provide clean heat evenly and efficiently. They're compact and highly customizable, providing a maximum process work area while consuming minimal chemicals. Wetted surfaces feature all-PFA materials, and may be used in tanks made of PVDF, PFA, or quartz.
BOTH AGGRESSIVE CHEMISTRIES AND DEIONIZED WATER
These rugged and durable heaters come in grid, frame, and fence models, with outputs of 1.0 to 30.0 kW. They feature a low watt density (≤ 4 watts/in²) for fast heating response and integrate easily into most process tanks. Provide Surplus with your specifications and tank size for a custom immersion heater solution.
SAFETY FEATURES
At the heart of these immersion heaters is the patented PreciseHeater heating coil, with > 99% efficiency and MTBF of more than 10 years. A microprocessor-based temperature controller regulates heater output. Optional safety features include platinum and embedded ground wires, Type-J process thermocouple, and RTD over-temperature and process thermocouples.
KEY SPECIFICATIONS
Maximum heating temperature: 200°C (392°F) with ± 0.1°C accuracy (contingent on customer's facilitation). Grid heaters are typically ¾" high, and frame heaters 1½" high. Outputs range from 1.0 to 30.0 kW (dependent on customer voltage), from 120 VAC to 480 VAC, 1 or 3-ph (dependent on wattage).
Specifications
| Heater Element |
Heating Coil |
| Wetted Surfaces |
PFA/PTFE |
| Wattages |
1.0 - 20 kW |
| Voltages |
120 - 480 VAC
1 or 3 phase |
| Sizes (LxW) |
7x5 to 19x14 inch |
| Height |
1-5/8 inch |
| Temperature |
200°C (392°F) |
| Hi-Limit Sensor |
Type-J thermocouple |
| Ground Wire |
Encapsulated |
| Lead Wire |
15-ft |
