PTFE Frame Heater
>
Ultra High Purity PTFE Frame Heater with 200°C Heating Capability and Compact 1-5/8 Inch Height
  • Ultra High Purity PTFE Frame Heater with 200°C Heating Capability and Compact 1-5/8 Inch Height
  • Ultra High Purity PTFE Frame Heater with 200°C Heating Capability and Compact 1-5/8 Inch Height

Ultra High Purity PTFE Frame Heater with 200°C Heating Capability and Compact 1-5/8 Inch Height

Product Details:
Place of Origin: China
Brand Name: Surplus
Certification: ISO9001
Model Number: PTFE FH 027
Detail Information
Place of Origin:
China
Brand Name:
Surplus
Certification:
ISO9001
Model Number:
PTFE FH 027
Name:
Square Perimeter Heating PTFE Trame Immersion Heater For Semiconductor Ultra High Purity Heating
Supply Voltage (V/Phase)::
220V,380V,480V Or Others
Type Of Temperature Control:
PT100 Or J Type
Application:
Semiconductor, Solar, MEMs, And Other Technological Industries
Frame Material:
PTFE
Inside Material:
PFA
Cable Length:
2 Meters/3meters/others
Highlight:

High Light

Highlight:

Square PTFE frame immersion heater

,

Semiconductor ultra high purity heater

,

PTFE perimeter heating immersion heater

Trading Information
Minimum Order Quantity:
1 PCS
Price:
Contact Us
Packaging Details:
Wooden Case or Carton Box
Delivery Time:
10-15 working days
Payment Terms:
TT, Paypal, Western Union
Supply Ability:
50 PC/Month
Product Description
Square perimeter heating PTFE Trame Immersion Heater For Semiconductor Ultra High Purity Heating
PFA Frame heaters are the perfect solution for heating harsh chemicals or DI water to constant temperatures in ultrapure tanks, including PVDF, PFA, and quartz tanks. Their PFA/PTFE wetted surfaces are ideal for use in high-purity applications where chemical compatibility is of utmost importance. PFA immersion tank heater provide high-efficiency heating with superior temperature control and maximum power output in a compact footprint. The heaters are available in various sizes that easily fit new and existing systems common to semiconductor, solar, MEMs, and other technological industries.
Ultra High Purity PTFE Frame Heater with 200°C Heating Capability and Compact 1-5/8 Inch Height
Features & Benefits
  • Ultrapure PTFE/PFA wetted surfaces
  • Reliable heating of harsh chemicals
  • Maximum power in compact footprint
  • Maximum 200°C heating capability
  • Fast temperature response and efficiency
  • Each configuration capable of various voltage-to-wattage combinations
  • Integrate easily into most PVDF, PFA, and quartz wet process tanks
  • Sizes for many tank dimensions
  • Compact height of 1-5/8 inch
  • Safety features include hi-limit sensor and encapsulated ground wire
  • No N2 purge required
Specifications
Heater Element Heating Coil
Wetted Surfaces PFA/PTFE
Wattages 1.0 - 20 kW
Voltages 120 - 480 VAC
1 or 3 phase
Sizes (LxW) 7x5 to 19x14 inch
Height 1-5/8 inch
Temperature 200°C (392°F)
Hi-Limit Sensor Type-J thermocouple
Ground Wire Encapsulated
Lead Wire 15-ft

Optional Perforated Grids


  • Top grids separate heaters from wafer carriers and components to increase the available tank space
  • Bottom grids separate heaters from the tank floor
  • Available for all frame sizes
  • Adds 1/8 inch to height
Industries
  • Semiconductor Fabrication
  • Solar Cell Manufacturing
  • Flat-Panel Display, LEDs & Electronics
  • Chemicals Manufacturing
  • Industrial Manufacturing



Point Of Use Heating
Point of Use (POU) Heating refers to the energy-efficient method of placing small heaters near processing baths to reduce heat-up wait times.
Applications:
  • Semiconductor Wafer Cleaning
  • Etching
  • Inline Chemical Heating
  • Point of Use Heating (POU)
High-Purity PFA Inline Chemical Heater
2KW, 4KW, 6KW, 12KW, 18KW Inline Chemical Heater
PTFE Inline Heater
PFA In-Line Heater
Inline Chemical Heater
Inline Chemical Heater
