| Place of Origin: | China |
| Brand Name: | Surplus |
| Certification: | ISO9001 |
| Model Number: | PFA Immersion Tank Heater 16 |
| Component | Specification |
|---|---|
| Wetted Surfaces | PFA/PTFE |
| Wattages | 1.0 - 20 kW |
| Voltages | 120 - 480 VAC (1 or 3 phase) |
| Dimensions (LxW) | 7x5 to 19x14 inches |
| Height | 1-5/8 inches |
| Temperature Rating | 200°C (392°F) |
| Hi-Limit Sensor | Type-J thermocouple |
| Ground Wire | Encapsulated |
| Lead Wire | 15-ft |
| Model | kW Range | Height | Benefits |
|---|---|---|---|
| Grid | 1-6 kW* | 3/4 in | Low Profile Design |
| Frame | 1-30 kW | 1-1/2 in | Low Profile Design for Higher kW's |
| Fence | 1-10 kW | Variable | Side-mounted heater leaves tank center open |
Electrochemical Deposition is a cost-effective process using oxidation and reduction to adhere metal to surfaces through electrical current. Also known as Electro-Plating, our solutions deliver full power supply output performance with high efficiency, high-speed DC output, connectivity, reliability, and ETL certification.
Compact metal over-the-side heater ideal for laboratory and small tank applications. Heats up to 300°F (149°C). Single phase. 500-1500 watts, 120-240 volts.
Over-the-side, 3-element tubular heater. Three phase. 3000-10500 watts, 208-600 volts.
Derated, low watt density metal over-the-side heater. Single or three phase. 500-6000 watts, 120-600 volts.
Low-watt density spiral heater with fluoropolymer (PTFE) sleeved 304 stainless elements. 500-6000 watts, 120-600 volts.
Metal flanged heater available in 3″, 5″ and 6″ flange sizes. 3000-72000 watts, 208-600 volts.
Metal Immersion Coil in U shape for chemical heating/cooling with minimal recovery time. Available in steel, 316 stainless steel and titanium.
