| Place of Origin: | China |
| Brand Name: | Surplus |
| Certification: | ISO9001 |
| Model Number: | SUS316 N2 Heater 03 |
| Heater | N2 SS Heater |
|---|---|
| Wetted Surface | 316L Stainless Steel Electropolish |
| Sizes | 375 - 3000 Watts (Dependent on Voltage) |
| Voltages | 120 VAC to 240 VAC 1-Phase (Dependent on Wattage) |
| Temperature | 392°F (200°C) |
| Pressure | 60 PSIG at 200°C |
Application
1. Inert gas heating for semiconductor, liquid crystal and organic EL manufacturing equipment;
2. High-purity gas heating for analyzers, small test equipment;
3. Gas heating for combustion gas simulation tests;
4. Small-volume gas heating during chemical material production;
5. Atmosphere gas heating in heat treatment furnaces.
Product Features & Advantages
1. Heating with high-purity nitrogen ensures clean heating performance for target gas;
2. All wetted parts (gas contact sections) are made of stainless steel to achieve contamination-free heating;
3. The heating element is isolated from the gas flow channel. The target gas will not come into contact with the heater surface for pure heating;
4. Outlet temperature adjustable up to 500°C (flow rate: 2~30 L/min);
5. Low surface temperature of main body. When outlet temperature reaches 350°C, housing surface temperature is only 50°C, no thermal insulation materials required;
6. Palm-sized compact unit, weight approx. 350g. Flexible installation space, can be mounted close to the heating point;
7. Unique structure delivers high thermal efficiency: efficiency ≥80% at flow rate above 10 L/min;
8. Thermocouple equipped as standard for temperature control and over-temperature protection.
